Sanwa/Airtronics 92081 RX-481 2.4GHz 4-Channel FHSS-4 Receiver w/Internal Antenna

This is the Sanwa RX-481 2.4Ghz FHSS-4 4-Channel Surface Receiver, with a built-in Internal Antenna. The RX-481 Super Response receiver features a built-in antenna! This means no more antennas sticking out of the body, as well as no more worry about damaging the antenna during use. Just mount the RX-481 Super Response receiver in the upright position in your model and enjoy the same solid reception as you’ve come to expect from other Sanwa surface receivers.

The RX-481 Super Response receiver is compatible with Airtronics and Sanwa 2.4GHz FH3 and FH4T transmitters, such as the M12S, M12, MT-4S, MT-4, MX-3X, M11X, EXZES-Z and Gemini X. It features an extremely low latency time and high frame rate, which makes you feel more connected to your model than ever, and when combined with Airtronics or Sanwa Super Response SRG digital servos (available separately), the RX-481 Super Response receiver will deliver reaction speeds like never before!

Features:

• Built-In Internal Antenna – No More Unsightly External Antenna
• Compatible with Sanwa and Sanwa FH3 and FH4T Transmitters
• Extremely Low Latency and High Frame Rate Makes You Fell More Connected to Your Model
• Supports Normal, SSR and SHR Channel Response Modes (Requires Compatible Transmitter)
• Compatible with Sanwa and Sanwa SRG Digital Servos

Specifications:
Frequency: 2.4GHz FH3/FH4T Selectable Via Transmitter
Nominal Input Voltage: 4.8 to 7.4 Volts (4-6C NiCD/MH, 2S LiFe or 2S LiPo)
Weight: 0.25oz (7.1g)
Dimensions: 0.71 x 0.96 x 1.06in (18.2 x 24.4 x 27.1mm)
Battery Fail Safe Limit: 3.5 to 5.0 Volts (FH3) / 3.5 to 7.4 Volts (FH4T)

NOTE:

• Although the reception capability of this receiver is equal to our other receivers that feature an external antenna, because the internal antenna is positioned lower in your model, the reception distance will be shorter in actual use.
• Do to the internal antenna position, this receiver is not suitable for use in an R/C boat. It should be used in R/C cars and trucks only.
• Super Response (SSR) feature only available when used with an Airtronics or Sanwa FH4T transmitter in SSR Channel Response Mode with Airtronics or Sanwa Super Response SRG digital servos.

This product was added to our catalog on April 27, 2016
